Reagent Dosing System Design

A chemical name alone is not enough to specify dosing equipment. Concentration, temperature, density, viscosity, impurities, and preparation method can all change the duty.

Gold and mineral-processing plants may handle sodium cyanide, xanthates, MIBC, caustic soda, sulfuric acid, hydrochloric acid, sodium metabisulfite, and other reagents with very different characteristics.

Before pump selection, the chemical assessment should establish:

• concentration and temperature range
• viscosity and density
• corrosiveness and material compatibility
• suspended solids, if present
• crystallization or precipitation risk
• vapor and exposure hazards
• flushing and cleaning requirements

These properties influence the entire dosing path, including the pump, seals, valves, pipework, gaskets, instruments, and containment.

A dosing system should accommodate minimum, normal, and maximum demand. Selecting a pump only for peak flow can create poor control during normal operation. If the pump is too large, small speed changes may produce relatively large dosing adjustments. If it is too small, it may lack capacity when throughput or chemical demand rises.

The specification should account for:

• minimum continuous flow
• normal operating flow
• maximum process demand
• startup or upset conditions
• required adjustment resolution
• potential future capacity changes

Pressure must also be calculated across the complete system. This includes static elevation, pipe friction, valves, fittings, instruments, injection equipment, and the maximum pressure at the receiving process.

The pump should maintain predictable delivery across this range. If output changes whenever discharge pressure moves, the dosing setpoint no longer represents a dependable chemical flow.

Many dosing problems begin upstream of the pump. Long suction lines, restrictive valves, insufficient head, trapped gas, unsuitable tank placement, or poor draw-off arrangements can make delivery unstable.

The suction route should be short and direct where practical. Unnecessary restrictions should be avoided, particularly with viscous reagents or chemicals that may crystallize. Tank level and pressure conditions should remain suitable throughout operation, not only when the vessel is full.

Where a reagent contains suspended solids, storage and mixing should maintain a representative concentration at the pump inlet. The pump cannot deliver a consistent dose if its feed changes because material settles or separates.

Startup, shutdown, tank refilling, and low-level operation should also be considered. Repeatable dosing requires a stable chemical supply.

Chemical compatibility must extend from storage to injection. A corrosion-resistant pump body does not protect the system if seals, valve seats, gaskets, instruments, or pipework are unsuitable.

Every wetted component should be checked against the actual reagent concentration and temperature. Compatibility with cleaning and flushing liquids must also be considered, since they may create a different chemical environment.

Material failure does not always begin with a visible leak. Swelling, hardening, corrosion, or gradual loss of strength can change equipment performance before complete failure occurs. Correct material selection protects containment, availability, and dosing repeatability.

Hourly chemical consumption does not show how reagent enters the process from moment to moment. A pump may deliver the correct total volume while introducing repeated surges and low-flow intervals.

Steady delivery creates a clearer relationship between pump adjustment and chemical response. It also supports more stable flow measurement and reduces pressure fluctuations that can affect valves, instruments, pipework, and injection equipment.

The instrumentation arrangement should verify what reaches the process, not only what the pump has been instructed to deliver. Depending on the chemical and process risk, useful measurements may include:

• reagent flow
• tank level
• line pressure
• temperature
• concentration
• the process variable affected by dosing

Pressure monitoring can reveal closed valves, line restrictions, crystallization, or blocked injection points. Tank-level measurement helps protect the pump from losing its chemical supply.

A dosing adjustment may not produce an immediate measured response. The chemical needs time to move through the line, disperse, mix, react, and reach the measurement point.

If the control system responds too quickly, another correction may be issued before the result of the first change becomes visible. The process can then oscillate around the target.

Control logic should reflect transport delay, mixing time, reaction time, and sensor location. Feed-forward signals such as process flow or solids loading can establish an initial dose. Feedback from pH, concentration, recovery, or another process measurement can then refine it.

Good control logic still depends on predictable pump delivery. It cannot compensate indefinitely for unstable chemical flow.

Mining chemicals may be corrosive, hazardous, flammable, or environmentally harmful. Containment and leakage prevention should therefore be part of the initial design.

Depending on the reagent and site requirements, measures may include bunding, protected connections, drainage, leak detection, isolation valves, ventilation, and controlled access. Equipment may also need to be drained, isolated, flushed, or decontaminated before service.

Maintenance access affects dosing performance as well as availability. Wear, corrosion, seal condition, and deposits can gradually change pump output. A system that supports inspection, calibration checks, and timely service is more likely to preserve the relationship between pump command and actual flow.

SEEPEX MD and BN pumps use the progressive cavity pump principle. Fixed-shape cavities formed between the rotor and stator carry defined volumes from suction to discharge, producing controlled volumetric delivery with pulse-free flow. Output is adjusted through rotational speed, creating a direct relationship between pump operation and reagent flow.

The table provides initial direction rather than a complete selection rule. Final pump selection should consider the full flow range, operating pressure, concentration, temperature, viscosity, suction conditions, compatibility, and required control resolution.

Where maintenance effort influences availability, SCT and SSH can simplify access to key components and reduce service disruption.

A reagent setpoint should represent a predictable chemical input. Achieving that requires the chemical, pump, lines, instruments, controls, containment, and maintenance strategy to work as one system.

SEEPEX MD metering pumps support precise lower-flow dosing, while BN pumps extend controlled, pulse-free delivery to larger reagent volumes. The correct choice depends on the complete chemical duty and operating range.

When these elements are aligned, the process receives the reagent the control system intended to deliver. That is the purpose of effective reagent dosing system design: not simply to move chemicals, but to make every dosing command meaningful.
